Linear/Osco Z-Wave Smart Relay and Sensor Module - FGBS-222-US
Details
Linear/Osco Z-Wave Smart Relay and Sensor Module - FGBS-222-US
Legacy alarms, float switches, and analog devices can join modern smart home networks through a compact bridge module. Two configurable inputs accept either binary contacts or 0-10V analog signals. Additional terminals support up to six DS18B20 temperature probes or one DHT22 humidity sensor. Broad 9-30V DC compatibility works with many existing control panels and power supplies. Integrators preserve older hardware while adding remote monitoring and automation capabilities.
Key Features:
- Z-Wave Plus interface for retrofitting wired sensors
- Two configurable inputs for binary or 0-10V analog signals
- Supports up to 6 DS18B20 temperature probes or 1 DHT22 sensor
- 9-30V DC powered for broad equipment compatibility
Specifications
- Part Number: FGBS-222-US
- Protocol: Z-Wave Plus
- Inputs: 2 configurable inputs plus sensor terminals
- Power Supply: 9-30V DC
| SKU | FGBS-222-US |
|---|---|
| UPC Code | 8.44039E+11 |
| Manufacturer | Nice North America / Linear PRO Access / OSCO |
| Condition | New |
