Linear/Osco OSCO-725-25F Drop-In Heavy-Duty Replacement Commercial Slide Gate Opener (2500lb Rating, Fast)

Long lines at a slow-moving gate are a problem of the past with this high-speed operator. The Linear/Osco Drop-In Heavy-Duty Replacement Commercial Slide Gate Opener (2500lb Rating, Fast) is rated for gates up to 2,500 lb and 100 ft, and its 1 HP brushless DC motor opens large gates at roughly double the speed of standard operators, making it ideal for parking facilities, guard gates, and busy industrial entrances. Special features include travel speeds up to 2.25 ft/s, UPS-standard battery backup, and the SmartTouch 725 controller with over 70 configurable settings and smartphone app programming.

Features:

• 1 HP brushless DC motor with direct-drive gearbox and manual release
• High-speed rate of travel: 1.75, 2, or 2.25 ft/s, double the speed of standard operators
• Continuous duty cycle for high-traffic entrances and guard gates
• UPS-standard battery backup keeps the gate operating after AC power loss
• SmartTouch 725 controller with 70+ user settings
• Bluetooth Low Energy connection to smartphone Installer App for wireless programming and diagnostics
• Contactless limit sensing for end-of-travel in both directions
• Steel enclosure with powder coat finish and rodent-resistant locking cover
• Includes 45 ft of #50 corrosion-resistant roller chain, MegaCode receiver, and 1 transmitter

Specifications:

• Duty Cycle: Continuous Duty
• Motor: 1 HP Brushless
• Gear Box: Direct Drive with Manual Release
• Max. Gate Length: 100 ft (30 m)
• Max. Gate Weight: 2,500 lbs. (1,134 kg)
• Operating Voltage: 24 VDC
• Input Voltage: 115 V or 208-230 V, 50/60Hz
• Finish: Powder-coated steel with Zinc
• UL 325 Usage Class: I, II, III, IV
• Warranty: 5 years
